dCS Lina Headphone Amplifier

10.750

On Show in the Shop.

SKU: N/A Categories: ,

Description

Our powerful solid state amplifier is designed to drive even the most demanding headphones to their full potential.
– Drives a vast range of headphones, including IEMs and planars.
– Complements virtually any headfi setup.
– Unique design offers exceptional sonic and measured performance.

• Low output impedance ensures optimal sound with a huge range of headphones – including highly sensitive models

• Solid state design provides consistent, clean performance

• Choice of inputs caters to a variety of digital sources and audio setups

• Class AB design with DC servo system delivers high power efficiency and excellent linearity

• Billet Aluminium chassis reduces risk of electromagnetic interference

• Transparent performance faithfully mirrors the sound of your chosen music and headphones

Dimensions / Weight
121.5mm (H) x 220mm (W) x 356mm (D) / 7.5kg

Headphone Outputs
• 1 x dual 3-pin balanced XLR, right and left channel
• 1 x single 4-pin balanced XLR
• 1 x single 1⁄4” (6.35mm) headphone jack

Signal to Noise Ratio
110dB 20Hz-20kHz A-weighted
(referenced to 6V rms balanced input and output)

Analogue Inputs
• 1 x stereo pair unbalanced RCA, input impedance 48kΩ
• 1 x stereo pair unbuffered balanced XLR, input impedance 16kΩ
• 1 x stereo pair buffered balanced XLR, input impedance 96kΩ

THD+N
<0.005% @ 1kHz 6V rms balanced output into 30Ω (80kHz bandwidth)

Frequency Response
1Hz-100kHz Better than +0/-3dB

Additional information

Color

Black, Silver, Black Overstock Sale

Brand

dCS
